Reducer Tube Adaptor with Swivel Nut

Name: Reducer Tube Adaptor with Swivel Nut
Rating: 5 (99 reviews)

Product Description
hydraulic adaptor metric male O-Ring flat sealing pipe fittings

Model No.: 1E. 1E9.AE.2E9.4E.9E.1EH.1EH9-OG
Material: Carbon Steel, Stainless Steel
Surface Treatment: White or Yellow Zinc-Plated
Standards: Eaton, DIN, ISO, SAE, JIC or As customers' drawing
Export Markets: Global

Get A Quote

PREV：Eaton Standard Ce Approved 90 Elbow Tube Fitting Bc. Bd Bc-Rn, Bd-Rn
SUSUNOD：Metric Male 74 Degree Cone Fitting/Sea O-Ring Boss L-Series ISO 11926-3 (1QO, 1QO-RN)

Specification
Contact Us

Standard:	DIN
Material:	Medium Carbon Steel
Connection:	Female
Surface Treatment:	Galvanized Sheet
Head Type:	Round
Manufacturer:	Factory

PART NO.	THREAD E	THREAD F	TUBE O.D. D1	TUBE O.D D2	DIMENSIONS A	DIMENSIONS B	DIMENSIONS S1	DIMENSIONS S2	DIMENSIONS L
PART NO.	THREAD E	THREAD F	TUBE O.D. D1	TUBE O.D D2	DIMENSIONS A	DIMENSIONS B	DIMENSIONS S1	DIMENSIONS S2	DIMENSIONS L
2C -14-16	M14X1.5	M16X1.5	8	10	13	2	17	22	40
2C -14-18	M14X1.5	M18X1.5	8	12	13	2.5	17	24	41
2C -16-18	M16X1.5	M18X1.5	10	12	13.5	2.5	17	24	41.5
2C -16-22	M16X1.5	M22X1.5	10	15	13.5	2.5	22	27	46
2C -18-22	M18X1.5	M22X1.5	12	15	13.5	2.5	22	27	46
2C -18-26	M18X1.5	M26X1.5	12	18	13.5	2.5	27	32	49.5
2C -22-26	M22X1.5	M26X1.5	15	18	13.5	2.5	27	32	49.5
2C -22-30	M22X1.5	M30X2	15	22	13.5	4	30	36	52.5
2C -26-30	M26X1.5	M30X2	18	22	14	4	30	36	53
2C -26-36	M26X1.5	M36X2	18	28	14	4	36	41	54
2C -30-36	M30X2	M36X2	22	28	18	4	36	41	58
2C -30-45	M30X2	M45X2	22	35	18	5	46	55	65.5
2C -36-30	M36X2	M30X2	28	22	18	4	41	36	60
2C -36-45	M36X2	M45X2	28	35	18	5	46	55	65.5
2C -36-52	M36X2	M52X2	28	42	18	5.5	50	60	69
2C -45-52	M45X2	M52X2	35	42	19	5.5	50	60	70

About OPK Fitting

OPK FITTING Hydraulic Equipment Factory is a specialized domestic factory with hydraulic pipes and adaptors production experience. Our managing scope relates to various fields such as hydraulic systems etc.; Including all kinds of materials with different pressure levels, flexible hydraulic hoses with various size criteria, hose fitting, adaptor, etc. They have been respectively applied in the hydraulic and fluid conveyance systems of industries, such as machinery, metallurgy petroleum, construction, ships, space-flight, agriculture, pharmaceutical, food, and so forth.
Ningbo OPK Fitting Co., Ltd. is a China professional Reducer Tube Adaptor with Swivel Nut manufacturers and ODM & OEM Reducer Tube Adaptor with Swivel Nut factory .We can provide custom-made stainless steel hydraulic fittings, hydraulic hose crimp fittings, and hydraulic quick couplings.

Over 10 years of experience.

A team of skilled design professionals and talent.

Excellent product quality and thoughtful customer service.
